37 Degree Flare Female Elbow Fittings

Stainless Steel 304/304L,316/316L,904L 37 Degree Flare 45 Deg Male Elbow Manufacturer

Inconel 600/625, Incoloy 800/800H, Monel 400/K500, Nickel 200/201, Hastelloy C22, C276 37 Degree Flare 45 Deg Male Elbow Manufacturer & Exporter

Duplex Steel 2205, Brass Alloy Instrumentation 37 Degree Flare 45 Deg Male Elbow Fittings Supplier & Trader

METAL MINISTRY INC. is one of the leading 37 Degree Flare 45 Degree Male Elbow Fittings Manufacturer, Exporter & Supplier. We are a prestigious maker of best quality Union Elbows that discover application for joining the two tubes at various points. Produced using high thickness steel and metal these Union Elbows are exceptionally tough and rust free. Fittings can be similarly coupled to metric or inch tubes. These are accessible in various strings for various pipe OD's and guarantee a leaf confirmation joint. We create these union elbows keeping into thought the set mechanical benchmarks, which makes our range most looked for after in the worldwide commercial center.
37 Degree Flare 45 Deg Male Elbow Exporter

Stainless Steel 304/304L 37 Degree Flare 45 Deg Male Elbow Fittings, Stainless Steel 316/316L 37 Degree Flare 45 Deg Male Elbow Fittings, Stainless Steel 904L 37 Degree Flare 45 Deg Male Elbow Fittings, Inconel 600 37 Degree Flare 45 Deg Male Elbow Fittings, Inconel 625 37 Degree Flare 45 Deg Male Elbow Fittings, Incoloy 800/800H 37 Degree Flare 45 Deg Male Elbow Fittings, Monel 400 37 Degree Flare 45 Deg Male Elbow Fittings, Monel K500 37 Degree Flare 45 Deg Male Elbow Fittings, Nickel 200 37 Degree Flare 45 Deg Male Elbow Fittings, Nickel 201 37 Degree Flare 45 Deg Male Elbow Fittings, Hastelloy C22 37 Degree Flare 45 Deg Male Elbow Fittings, Hastelloy C276 37 Degree Flare 45 Deg Male Elbow Fittings, Duplex Steel 2205 37 Degree Flare 45 Deg Male Elbow Fittings, Brass Alloy 37 Degree Flare 45 Deg Male Elbow Fittings

Specification for 37 Degree Flare 45 Deg Male Elbow

45 Deg Male Elbow Stud End Thread: Npt
TUBE OD THREAD
UN / UNF		 THREAD
NPT/NPTF		 S L L1 D PART
NO.
mm inch N N2 mm mm mm mm
6 1/4 7/16 -20 1/8-27 11 18.3 16.3 4.4 4-2F-AMEN
6 1/4 7/16 -20 1/4-18 14 20.8 21.8 4.4 4F-AMEN
8 5/16 1/2 -20 1/8-27 13 19.6 16.3 6 5-2F-AMEN
8 5/16 1/2 -20 1/4-18 14 20.8 21.8 6 5-4F-AMEN
10 3/8 9/16 -18 1/8-27 14 21.1 21.8 7.5 6-2F-AMEN
10 3/8 9/16 -18 1/4-18 14 21 17 7.5 6-4F-AMEN
10 3/8 9/16 -18 3/8-18 19 22.1 24.1 7.5 6F-AMEN
10 3/8 9/16 -18 1/2-14 22 22.4 29.7 7.5 6-8F-AMEN
12 1/2 3/4 -16 1/4-18 19 25 24 9.9 8-4F-AMEN
12 1/2 3/4 -16 3/8-18 19 24.9 24.1 9.9 8-6F-AMEN
12 1/2 3/4 -16 1/2-14 22 24.9 29.7 9.9 8F-AMEN
12 1/2 3/4 -16 3/4-14 27 26.5 30.5 9.9 8-12F-AMEN
14/15/16 5/8 7/8 -14 3/8-18 22 28 25 12.3 10-6F-AMEN
14/15/16 5/8 7/8 -14 1/2-14 22 28.2 29.7 12.3 10-8F-AMEN
14/15/16 5/8 7/8 -14 3/4-14 27 29.5 30.5 12.3 10-12F-AMEN
18/20 3/4 1 1/16 -12 1/2-14 27 32.5 30.5 15.5 12-8F-AMEN
18/20 3/4 1 1/16 -12 3/4-14 27 32.5 33 15.5 12F-AMEN
18/20 3/4 1 1/16 -12 1-11.5 33 36 32.5 15.5 12-16F-AMEN
25 1 1 5/16 -12 3/4-14 33 37.5 37.6 21.5 16-12F-AMEN
25 1 1 5/16 -12 1-11.5 33 37.3 37.6 21.5 16F-AMEN
28/30/32 1 1/4 1 5/8 -12 1 1/4-11.5 41 40.4 42.4 27.5 20F-AMEN
35/38 1 1/2 1 7/8 -12 1 1/2-11.5 48 45.2 45 33 24F-AMEN

45 Deg Male Elbow Stud End Thread:BSPT
TUBE OD THREAD
UN / UNF		 THREAD
BSPT		 S L L1 D PART
NO.
mm inch N N2 mm mm mm mm
6 1/4 7/16-20 1/8-28 11 18.3 16.3 4.4 4-2F-AMER
6 1/4 7/16-20 1/4-19 14 20.8 21.8 4.4 4F-AMER
8 5/16 1/2-20 1/8-28 13 19.6 16.8 6 5-2F-AMER
8 5/16 1/2-20 1/4-19 14 20.8 21.8 6 5-4F-AMER
10 3/8 9/16-18 1/4-19 14 21.1 21.8 7.5 6-4F-AMER
10 3/8 9/16-18 3/8-19 19 22.1 24.1 7.5 6F-AMER
10 3/8 9/16-18 1/2-14 22 22.4 29.7 7.5 6-8F-AMER
12 1/2 3/4-16 3/8-19 19 24.9 24.1 9.9 8-6F-AMER
12 1/2 3/4-16 1/2-14 22 25.2 29.7 9.9 8F-AMER
14/15/16 5/8 7/8-14 1/2-14 22 28.2 29.7 12.3 10-8F-AMER
18/20 3/4 1 1/16-12 3/4-14 27 32.5 30.5 15.5 12F-AMER
25 1 1 5/16-12 1-11 33 37.3 37.6 21.5 16F-AMER
28/30/32 1 1/4 1 5/8-12 1 1/4-11 41 40.4 42.4 27.5 20F-AMER
35/38 1 1/2 1 7/8-12 1 1/2-11 48 45.2 45 33 24F-AMER

45 Deg Male Elbow Stud End Thread: BSP
TUBE OD THREAD
UN / UNF		 THREAD
BSPT		 S L L1 S1 D PART
NO.
mm inch N N2 mm mm mm mm mm
6 1/4 7/16-20 1/8-28 11 18.3 26.5 14 4.4 4-2F-AMEG
6 1/4 7/16-20 1/4-19 14 20.8 29 19 4.4 4F-AMEG
8 5/16 1/2-20 1/8-28 13 19.6 26.5 14 6 5-2F-AMEG
8 5/16 1/2-20 1/4-19 14 20.8 29 19 6 5-4F-AMEG
10 3/8 9/16-18 1/4-19 14 21.1 29 19 7.5 6-4F-AMEG
12 1/2 3/4-16 3/8-19 19 24.9 33 22 9.9 8-6F-AMEG
12 1/2 3/4-16 1/2-14 22 25.2 38.5 27 9.9 8F-AMEG
14/15/16 5/8 7/8-14 1/2-14 22 28.2 38.6 27 12.3 10-8F-AMEG
14/15/16 5/8 7/8-14 3/4-14 27 29.5 44 36 12.3 10-12F-AMEG
18/20 3/4 1 1/16-12 3/4-14 27 32.5 44 36 15.5 12F-AMEG
25 1 1 5/16-12 1-11 33 37.2 47 41 21.5 16F-AMEG
28/30/32 1 1/4 1 5/8-12 1 1/4-11 41 40.4 48 50 27.5 20F-AMEG

45 Deg Male Elbow Stud End Thread: UNF
TUBE OD THREAD
UN / UNF		 THREAD
NPT/NPTF		 S L L1 S1 D PART
NO.
mm inch N N2 mm mm mm mm mm
6 1/4 7/16-20 7/16-20 11 18.3 26.7 14 4.4 4-7F-AMEU
8 5/16 1/2-20 1/2-20 13 19.6 26.7 17 6 5-8F-AMEU
10 3/8 9/16-18 9/16-20 14 21.1 29 17 7.5 6-9F-AMEU
10 3/8 9/16-18 3/4-16 19 24.9 29.7 17 7.5 6-12F-AMEU
12 1/2 3/4-16 3/4-16 19 24.9 33 22 9.9 8-12F-AMEU
12 1/2 3/4-16 7/8-14 22 25.2 38.6 27 9.9 8-14F-AMEU
14/15/16 5/8 7/8-14 3/4-16 22 28.2 34.5 22 12.3 10-12F-AMEU
14/15/16 5/8 7/8-14 7/8-14 22 28.2 38.6 27 12.3 10-14F-AMEU
18/20 3/4 1 1/16-12 7/8-14 27 32.5 39.8 27 15.5 12-14F-AMEU
18/20 3/4 1 1/16-12 1 1/16-12 27 32.5 43.9 32 15.5 12-17F-AMEU
25 1 1 5/16-12 1 5/16-12 33 37.3 47.2 41 21.5 16-21F-AMEU
28/30/32 1 1/4 1 5/8-12 1 5/8-12 41 40.4 48.5 50 27.5 20-26F-AMEU
35/38 1 1/2 1 7/8-12 1 7/8-12 48 45.2 48.5 55 33 24-30F-AMEU

Exports for 37 Degree Flare 45 Deg Male Elbow

Metal Ministry inc. exports 37 Degree Flare 45 Deg Male Elbow in various countries like India, Saudi Arabia, Bangladesh, United States, United Arab Emirates, Canada, Angola, Argentina, Austria, Azerbaijan, Pakistan, Peru, Chile, Spain, France, United Kingdom, Indonesia, Israel, Iran, Kuwait, Mexico, Malaysia, Nigeria, Serbia, Singapore, Taiwan, Chile, Venezuela, Ecuador, Netherlands, Brazil, Colombia, Ghana, Iran, Denmark, Poland, Australia, Afghanistan, Bahrain, Costa Rica, Egypt, Iraq, Jordan, South Korea, Kazakhstan, Sri Lanka, Lithuania, Norway, Oman, Philippines, Poland, Qatar, Russia, Vietnam, South Africa, Nigeria, Mexico, Turkey, Hungary, Algeria, Belarus, Belgium, Bhutan, Bolivia, Bulgaria, Croatia, Czech Republic, Estonia, Finland, Greece, Italy, Japan, Libya, Romania, Thailand, Trinidad & Tobago,Tunisia, Ukraine, Yemen, Hong Kong, Gabon, China, Portugal, Switzerland, New Zealand, Sweden, Slovakia, Kenya, Lebanon, Morocco, Mongolia.

Metal Ministry inc. exports 37 Degree Flare 45 Deg Male Elbow in various cities like Mumbai, Thane, Navi Mumbai, Pune, Pimpri-Chinchwad, Vadodara, Kolkata, Gurgaon, Ahmedabad, New Delhi, Bengaluru, Chennai, Surat, Bhopal, Ulsan, Faridabad, Houston, Dubai, Seoul, Hyderabad, Singapore, Abu Dhabi, Tehran, Calgary, Noida, Riyadh, London, Coimbatore, Jakarta, Istanbul, Bangkok, Kuwait City, Sharjah, Muscat, Edmonton, Busan, Mexico City, Doha, Jeddah, Aberdeen, Cairo, Geoje-si, Perth, Santiago, Chandigarh, Indore, Kuala Lumpur, Rio de Janeiro, Dammam, Melbourne, Madrid, La Victoria, Bogota, Lahore, Los Angeles, Algiers, Chiyoda, Ankara, Ho Chi Minh City, Toronto, Hong Kong, Rajkot, Brisbane, Petaling Jaya, Ernakulam, Secunderabad, Gimhae-si, Al Jubail, Port-of-Spain, Thiruvananthapuram, Milan, Atyrau, Lagos, Hanoi, Howrah, Sydney, Ahvaz, Karachi, New York, Caracas, Vung Tau, Al Khobar, Manama, Montreal, Granada, Courbevoie, Visakhapatnam, Ludhiana, Moscow, Dallas, Haryana, Colombo.

If you have any enquiries related to 37 Degree Flare 45 Deg Male Elbow feel free to get back to us on :- Telephone : +91-22-66109947 / +919892171042, Email : enquiry@metalministry.in
