Phosphor Bronze Alloy Wire Mesh

Quality Phosphor Bronze Alloy Wire Mesh Manufacturer

Phosphor Bronze Alloy - Phosphor Bronze Wire Mesh Manufacturer , Precision woven wire Phosphor Bronze Alloy filter mesh Exporter

Phosphor Bronze Alloy Wire Mesh, Wire Cloth and Screen Supplier & Trader are available at competitive price

METAL MINISTRY INC. is one of the leading Phosphor Bronze Alloy Wire Mesh Manufacturer, Exporter & Supplier. We make and supply different sorts of Phosphor Bronze Alloy Wire Mesh. The Wire Mesh fabricated and provided to our client is completely checked and tried. The crude material secured by us are from guaranteed and dependable sources. We contemplate each moment detail while maunfactureing these wire networks, whether it is uniform work tallying, or uniform wire thickness or quality of the wire work. We convey each specialized know how to deliver culminate wire networks for all our esteemed client.

Properties for Phosphor Bronze Alloy Wire Mesh

  • The compound phosphur bronze is a composite of copper(cu),Phosphor(p) and tin(pb).

  • Demonstrates resistance against wear and tear , erosion.

  • Demonstrates non attractive property.

  • Not reasonable against solid oxidizers and acids, for example, h2so4.


Are of Usage Phosphor Bronze Alloy Wire Mesh

  • Filteration in pharmaceutical ventures and nourishment preparing enterprises.

  • Fine wire material of phosphor bronze is utilized as a part of number of businesses, for example, porcelain dirt and particles,glass product ,filtration of fluid and gasses and so on.


Phosphor Bronze Alloy Wire Mesh Manufacturer Exporter

Phosphor Bronze Alloy Square Mesh / Fine mesh, Twill Weave (TW), Plain Dutch Weave Wire Mesh (PDW), Twill Dutch Weave Wire Mesh (TDW), Reverse Twill Dutch Weave (RTDW), Hollander Weave, Phosphor Bronze Alloy Wire Mesh, Phosphor Bronze Alloy Wire Mesh Manufacturer, Alloy Wire Mesh, Phosphor Bronze Wire Mesh, Phosphor Bronze Alloy Wire Mesh, Wire Mesh Suppliers, Phosphor Bronze Alloy Wire Mesh Screen, Wire Mesh of Phosphor Bronze Alloy with grades like 400,K-500


Specification For Phosphor Bronze Alloy Wire Mesh

mesh wire diameter opening (mm)
  SWG mm inch
6 22 0.711 0.028 3.522
8 23 0.610 0.024 2.565
10 25 0.508 0.020 2.032
12 26 0.457 0.018 1.660
14 27 0.417 0.016 1.397
16 29 0.345 0.014 1.243
18 30 0.315 0.012 1.096
20 30 0.315 0.0124 0.955
22 30 0.315 0.0124 0.840
24 30 0.315 0.0124 0.743
26 31 0.295 0.0116 0.682
28 31 0.295 0.0116 0.612
30 32 0.247 0.011 0.573
32 33 0.254 0.010 0.540
34 34 0.234 0.0092 0.513
36 34 0.234 0.0092 0.472
38 35 0.213 0.0084 0.455
40 36 0.193 0.0076 0.442
42 36 0.193 0.0076 0.412
44 37 0.173 0.0068 0.404
46 37 0.173 0.0068 0.379
48 37 0.173 0.0068 0.356
50 37 0.173 0.0068 0.335
60X50 36 0.0076 0.0076 -
60X50 37 0.0068 0.0068 -
60 37 0.0068 0.0068 0.250
70 39 0.132 0.0052 0.231
80 40 0.122 0.0048 0.196
90 41 0.112 0.0044 0.170
100 42 0.012 0.004 0.152
120X108 43 0.091 0.0036 -
120 44 0.081 0.3200 0.131
140 46 0.061 0.0024 0.120
150 46 0.061 0.0024 0.108
160 46 0.061 0.0024 0.098
180 47 0.051 0.002 0.090
200 47 0.051 0.002 0.076
250 48 0.041 0.0016 0.061
300 49 0.031 0.0012 0.054
325 49 0.031 0.0012 0.047
350 49 0.031 0.0012 0.042
400 49 0.031 0.0012 0.033
450 49 0.031 0.0012 0.029
500 50 0.025 0.0010 0.026

Exports for Phosphor Bronze Alloy Wire Mesh

Metal Ministry inc. exports Phosphor Bronze Alloy Wire Mesh in various countries like India, Saudi Arabia, Bangladesh, United States, United Arab Emirates, Canada, Angola, Argentina, Austria, Azerbaijan, Pakistan, Peru, Chile, Spain, France, United Kingdom, Indonesia, Israel, Iran, Kuwait, Mexico, Malaysia, Nigeria, Serbia, Singapore, Taiwan, Chile, Venezuela, Ecuador, Netherlands, Brazil, Colombia, Ghana, Iran, Denmark, Poland, Australia, Afghanistan, Bahrain, Costa Rica, Egypt, Iraq, Jordan, South Korea, Kazakhstan, Sri Lanka, Lithuania, Norway, Oman, Philippines, Poland, Qatar, Russia, Vietnam, South Africa, Nigeria, Mexico, Turkey, Hungary, Algeria, Belarus, Belgium, Bhutan, Bolivia, Bulgaria, Croatia, Czech Republic, Estonia, Finland, Greece, Italy, Japan, Libya, Romania, Thailand, Trinidad & Tobago,Tunisia, Ukraine, Yemen, Hong Kong, Gabon, China, Portugal, Switzerland, New Zealand, Sweden, Slovakia, Kenya, Lebanon, Morocco, Mongolia.

Metal Ministry inc. exports Phosphor Bronze Alloy Wire Mesh in various cities like Mumbai, Thane, Navi Mumbai, Pune, Pimpri-Chinchwad, Vadodara, Kolkata, Gurgaon, Ahmedabad, New Delhi, Bengaluru, Chennai, Surat, Bhopal, Ulsan, Faridabad, Houston, Dubai, Seoul, Hyderabad, Singapore, Abu Dhabi, Tehran, Calgary, Noida, Riyadh, London, Coimbatore, Jakarta, Istanbul, Bangkok, Kuwait City, Sharjah, Muscat, Edmonton, Busan, Mexico City, Doha, Jeddah, Aberdeen, Cairo, Geoje-si, Perth, Santiago, Chandigarh, Indore, Kuala Lumpur, Rio de Janeiro, Dammam, Melbourne, Madrid, La Victoria, Bogota, Lahore, Los Angeles, Algiers, Chiyoda, Ankara, Ho Chi Minh City, Toronto, Hong Kong, Rajkot, Brisbane, Petaling Jaya, Ernakulam, Secunderabad, Gimhae-si, Al Jubail, Port-of-Spain, Thiruvananthapuram, Milan, Atyrau, Lagos, Hanoi, Howrah, Sydney, Ahvaz, Karachi, New York, Caracas, Vung Tau, Al Khobar, Manama, Montreal, Granada, Courbevoie, Visakhapatnam, Ludhiana, Moscow, Dallas, Haryana, Colombo.

If you have any enquiries related to Phosphor Bronze Alloy Wire Mesh feel free to get back to us on :- Telephone : +91-22-66109947 / +919892171042, Email : enquiry@metalministry.in
